The Mass Flow Meter is designed based on the Coriolis force principle, delivering direct and highly accurate mass flow measurement without the need for temperature or pressure compensation.
Unlike traditional flow meters, it measures true mass flow and simultaneously provides multiple parameters including mass flow, volumetric flow, density, and temperature. Measurement accuracy remains stable regardless of fluctuations in temperature, pressure, or fluid density.
Widely used in oil & gas, LNG/CNG systems, chemical processing, energy, food & pharmaceutical industries, this solution is ideal for high-precision metering, custody transfer, and critical process control applications.
When fluid flows through the vibrating measuring tubes, Coriolis forces proportional to the mass flow are generated. These forces cause a slight phase shift (twist) in the tubes.
Sensors detect this phase difference, and the transmitter processes the signal to directly calculate:
Mass Flow Rate
Volume Flow Rate
Density
Temperature
This direct mass measurement ensures superior accuracy and stability under varying process conditions.
Mass flow accuracy up to ±0.1% ~ ±0.5%
Suitable for custody transfer and precision metering
Mass Flow
Volumetric Flow
Density
Temperature
(All from one instrument)
Direct mass measurement eliminates compensation errors.
No straight pipe run required
Can be installed horizontally, vertically, or inclined
Liquids
Gases
High-viscosity fluids
Slurries
Multi-phase flow
No moving mechanical parts
Low failure rate
Long service life
4–20 mA
HART
RS485 (Modbus)
Pulse output
Explosion-proof design (Ex d / Ex ia)
Corrosion-resistant materials
IP65 / IP67 protection
| Parameter | Specification |
|---|---|
| Measured Media | Liquid, Gas, Slurry, Multi-phase |
| Accuracy | ±0.1% ~ ±0.5% (Mass Flow) |
| Turndown Ratio | 100:1 ~ 1000:1 |
| Medium Temperature | -50°C to 200°C (Custom High/Low Temp Available) |
| Nominal Pressure | 1.6 MPa ~ 42 MPa |
| Nominal Diameter | DN3 – DN100 |
| Output Signal | 4–20 mA, HART, RS485, Pulse |
| Power Supply | 24VDC / 220VAC |
| Protection Rating | IP65 / IP67 |
| Explosion Rating | Ex dⅡBT4 / Ex iaⅡCT4 |
Sensor Assembly
Measuring tubes
Vibration driver
Signal detection elements
Transmitter
Signal processing unit
Digital display
Output module
Housing & Process Connection
Stainless steel / alloy materials
Flange / threaded / welded connections
LNG & CNG metering
Natural gas measurement
Refined oil & fuel custody transfer
Petrochemical raw materials
Acid & alkali solutions
Solvent dosing
Slurry measurement
Additive ratio control
Syrup
Dairy products
Pharmaceutical liquids
Hygienic process media
Reactor dosing
Mixing & blending
Closed-loop flow control
Install away from strong vibration sources
Ensure full pipe during operation (avoid gas bubbles in liquid measurement)
Proper grounding to prevent signal interference
Periodic inspection of seals and wiring
Recommended calibration interval: every 1–2 years (depending on process conditions)
International-level measurement accuracy
Stable performance in harsh industrial environments
Customizable design for high-pressure, cryogenic, or high-temperature applications
OEM & project-based engineering support
Fast global delivery for overseas projects
